EA Technology UltraTEV Plus² Online PD Surveyor
$285 per day ex GST, 1 to 7 days
Per day, AUD ex GST. The rate for your total hire length applies to every day, and the total never drops at a band change. Minimum hire one day. Australia-only hire; freight and handling quoted separately. Hiring for more than 90 days? Call for a long-term rate: 1300 730 499
Work out your hire
Pick your first and last day to see the hire charge.
| 7 days | $1,995 |
|---|---|
| 14 days | $3,591 |
| 28 days | $5,985 |
| 60 days | $10,773 |
- Delivery or collection
- Freight Australia-wide, quoted with availability, or collect from Hobart, Launceston, Adelaide or Newcastle. Urgent? Call 1300 730 499 rather than send the form.
- Datasheet
- Manufacturer's datasheet (PDF). Calibration certificate supplied with the instrument.
Overview
About the EA Technology UltraTEV Plus² Online PD Surveyor
Description
The Ultratev Plus² by EA Technology is a portable, non-intrusive test instrument for detecting and analysing partial discharge (PD) activity in medium-voltage (MV) and high-voltage (HV) equipment while energised and in service. Designed for online PD surveys, it uses a combination of ultrasonic and transient earth voltage (TEV) sensors to pinpoint internal and surface discharge across switchgear, cable terminations, transformers, and other HV assets. The instrument provides clear pass/fail results, real-time signal analysis, and historical comparison. It's an essential tool for condition-based maintenance, enabling early detection of insulation breakdowns before catastrophic failure.
Features
• Detects internal and surface partial discharge in energised equipment
• Dual-sensor detection: TEV (internal PD) and ultrasonic (surface PD)
• Suitable for MV/HV switchgear, cables, terminations, and transformers
• Non-intrusive testing: no shutdowns or isolation required
• Instant pass/fail condition assessment based on pre-set thresholds
• Real-time dB reading display and waveform capture
• Compatible with flexible airborne and contact ultrasonic sensors
• Built-in data storage and reporting via USB
• Lightweight, battery powered, and rugged for field use
• Supplied with sensors, headphones, charger, and carry case
Specifications
| TEV measurement | 0 to 60 dBmV, ±1 dB, 3 to 80 MHz pass band |
|---|---|
| Ultrasonic measurement | -7 to +71 dBµV, ±1 dB, 40 kHz sensor |
| Analysis | Phase-resolved PD (PRPD) and waveform display |
| Display | 3.5 in TFT touchscreen, 640 x 480 |
| Storage and connectivity | microSD up to 64 GB, Wi-Fi, NFC, micro USB |
| Battery | 3.7 V rechargeable lithium-ion, approx. 8 hours operation, approx. 6 hours to charge |
| Size | 201 x 76 x 34 mm |
| Weight | 0.44 kg |
| Operating environment | -20 to +50 °C, IP42 |
Manufacturer's published specifications. Your quote confirms the configuration supplied.
What’s in the case
- UltraTEV Plus2 main unit
- TEV probe
- Contact ultrasonic sensor
- Flexible airborne sensor
- Headphones
- Charger and USB cable
- Quick-start guide and application notes
- Carry case
Calibration
All Megavar test equipment is maintained under a documented calibration programme. Instruments are calibrated either by external calibration laboratories or in-house against reference standards that are themselves laboratory-calibrated, with measurement traceable to Australian national measurement standards held by the National Measurement Institute. A current calibration certificate is available on request. If your project requires a specific calibration interval, test standard, or documentation for a client submission, tell us at enquiry on 1300 730 499 and we will confirm what applies before you commit.
Often hired with
Related Equipment For Hire
Why hire from Megavar
A Tailored Hire Experience That Works for You
At Megavar, our dedicated test equipment hire division provides high-quality electrical testing instruments for both short and long-term use. Our team makes sure you receive the right tools, ready to go, every time. From fast dispatch to door-to-door freight, our hiring process is streamlined to get you up and running quickly and confidently.
- Rapid delivery and collectionDoor-to-door freight for minimal downtime
- Fast, simple bookingsPlace an order and we’ll handle the rest
- Fault supportIf a set plays up, call us and we will arrange a fix or a replacement.
Our 3-step easy process
Hiring Made Easy in 3 Simple Steps
Step 1: Request a Quote
Submit your rental request online, and our team will respond promptly with availability and pricing.
Step 2: Organise Your Rental
Once confirmed, we’ll quickly process your booking and dispatch the equipment. Delivery and collection can be arranged to suit your schedule.
Step 3: Use with Confidence
Supplied with the manufacturer’s manuals. If a set plays up, call us and we will arrange a fix or a replacement.
How the hire works
Hire terms in brief
After you enquire
We confirm availability, rates and freight in a written quote, valid for the period it states (usually 14 days). An enquiry or quote does not reserve equipment: the hire is booked when your purchase order, signed quote or email acceptance reaches us.
Hire period
Our carrier: up to 72 hours of transit each way is not charged as hire. Hire starts at delivery or 72 hours after dispatch, whichever is earlier, and ends at handover to our carrier or 72 hours before the equipment arrives back, whichever is later. Delay caused by us or our carrier is not charged. For example, dispatched Monday 10am and delivered Wednesday 2pm: hire starts Wednesday 2pm. Routes that normally take longer than 72 hours are marked on the quote. Your own freight: hire runs from handover to your carrier at our office until the equipment arrives back at our office. Collect in person: from collection to return.
Extensions and early return
Contact us before the return deadline to extend; your quoted rates stay fixed and extended hire is invoiced every 7 days. Return early and you pay only for the days used, at the rate band for the days actually hired.
Delivery and returns
Freight for each leg, the handling fee and any express dispatch are on the quote, before you accept. Returns go to the dispatching office named on the quote, by carrier or in person, never by post.
Counter times
Returned to our counter before 9am on a business day counts as the previous day. Collected after 4pm on a business day, hire starts the next day. Weekends and public holidays count as hire days.
Calibration and checks
Supplied in working order with listed accessories, leads and manuals. Each measuring instrument is calibrated, and its current NATA-traceable calibration certificate is available on request. If calibration falls due during your hire, we tell you before dispatch.
Cancelling or moving a booking
Cancel 5 or more business days before dispatch or collection and nothing is charged. With 2 to 4 business days’ notice, the charge is the greater of one day’s hire and 5% of the booked hire; with less notice, the greater of one day’s hire and 10%. You can ask once to move the start by up to 30 days, with at least 2 business days’ notice.
Loss, damage and insurance
The equipment is your responsibility, other than fair wear and tear, from the start of hire until it is back with us, including in transit, up to the replacement value cap shown on the quote for each item. No damage waiver is offered. We recommend you insure the equipment for its replacement value.
Payment and bond
Account customers pay each invoice within 14 days. Without a credit account, or paying by card, you pay the booked hire, freight, handling fee and any bond before dispatch. A bond applies only where the quote states one, and is refunded after return and inspection, less anything owed.
Summary of our Terms and Conditions: Test Equipment Hire. Full hire terms
Downloads
Enquire about EA Technology UltraTEV Plus² Online PD Surveyor Hire
When and where do you need it?
Send your hire dates and delivery location and we will confirm availability and lead time by the end of the next business day.
Or call us directly on 1300 730 499
Need help with your rental?
1300 730 499 We’re available Monday to Friday, 8:30 am to 5:00 pm. Urgent hire: call rather than send the form. rentals@megavar.com.auQuestions about this hire?
Call 1300 730 499 for availability, rates and booking. If a set plays up during the hire, call us and we will arrange a fix or a replacement. Counter collection and returns 8:30 am to 5:00 pm, Monday to Friday.
FAQ
Frequently Asked Questions
EA Technology UltraTEV Plus² Online PD Surveyor
What does the Ultratev Plus² do?
It detects and locates partial discharge activity in live, energised electrical equipment, helping you assess insulation condition without taking equipment offline.
What types of PD can it detect?
• TEV (Transient Earth Voltage) signals for internal PD
• Ultrasonic signals for surface discharge, such as tracking or corona
Which assets can it test?
It’s suitable for MV/HV metal-clad switchgear, transformers, cable joints and terminations, ring main units (RMUs), and GIS panels.
Does it require shutdown of equipment?
No. The Ultratev Plus² performs online testing, so no isolation or shutdown is needed, making it ideal for operational substations and industrial environments.
Is it easy to interpret the results?
Yes. It provides pass/fail alerts, dB readings, and waveform views. You can also compare results to historical readings for trend analysis.
Does it store test data?
Yes. It features internal memory and USB export, allowing users to generate reports or upload results to asset management systems.
What’s included in the rental?
• Ultratev Plus² main unit
• TEV probe, contact ultrasonic sensor, and flexible airborne sensor
• Headphones for live acoustic detection
• Charger, USB cable, and carry case
• Quick start guide and application notes
What support comes with the hire?
Each instrument is supplied with the manufacturer’s manuals. If a set plays up, call us and we will arrange a fix or a replacement.
What’s the minimum rental period?
The minimum hire is one day. The daily rate steps down for hires of 8 days or more, and longer project hires can be quoted on 1300 730 499.
Do you deliver across Australia?
Yes. We offer nationwide delivery and return pickup, or you may use your preferred freight provider.
